1000452
Attach Polymagnet - long range - 2D shear resistance
This magnet pairs with itself and the following:
This Polymagnet provides high holding force in magnet to magnet and magnet to steel applications, at design gaps greater than 1.5 mm. It also provides enhanced two dimensional shear resistance in magnet to magnet applications.
More Information
SKU: 1000452
Meta Description: 1000452
Part number: 1000452
Pairs with: 1000452
Availability date: Released
Base Polarity: North
Magnetization orientation: Through Thickness
Coating: Ni-Cu-Ni
Material: NdFeB
Grade: N40
Temperature Rating (C): 80
Temperature Grade: Standard
Shape type: Square
Length (inch): 0.75
Width (inch): 0.75
Thickness (inch): 0.062
Mass (oz): 0.1474
Length (mm): 19.05
Width (mm): 19.05
Thickness (mm): 1.587
Mass (g): 4.18
Countersink: 0
Magnet Family: Attach
Length fractional (inch): '3/4"
Alignment Functionality: 0
Shear resistance: Two Dimensional Shear
Latch Functionality: 0
Spring Functionality: 0
Torque Functionality: 0
Magnet Symmetry: 180
magnet_plate_length_range: 19.05
Indexing Feature: 0
Pairs well with
1000452
