1000571
Attach Polymagnet - long range - Self Aligning
This magnet pairs with itself and the following:
This Polymagnet provides a high holding force in magnet-to-magnet and magnet-to-steel applications, at design gaps greater than 0.75 mm. It also provides radial shear resistance in magnet-to-magnet applications.
More Information
SKU: 1000571
Meta Description: 1000571
Part number: 1000571
Pairs with: 1000571
Availability date: Released
Base Polarity: North
Magnetization orientation: Axial
Coating: Ni-Cu-Ni
Material: NdFeB
Grade: N50
Temperature Rating (C): 60
Temperature Grade: Standard
Shape type: Disc
Thickness (inch): 0.125
Outer diameter (inch): 0.75
Mass (oz): 0.2409
Thickness (mm): 3.175
Outer diameter (mm): 19.05
Mass (g): 6.83
Countersink: 0
Magnet Family: Attach
Alignment Functionality: Radial Alignment:
Shear resistance: Radial Shear
Latch Functionality: 0
Spring Functionality: 0
Torque Functionality: 0
Magnet Symmetry: Radial
magnet_disc_od_range: 19.05
magnet_disc_length_range: 1
Indexing Feature: 0
Pairs well with
1000571
