1000674

SKU: 1000674
Meta Description: 1000674
Part number: 1000674
Pairs with: 1000675
Availability date: Released
Base Polarity: South
Magnetization orientation: Axial
Coating: Ni-Cu-Ni
Material: NdFeB
Grade: N40
Temperature rating: 80
Temperature Grade: Standard
Dimensional tolerance: 0.127
Shape type: Ring
Thickness (inch): 0.125
Outer diameter (inch): 1
Inner diameter (inch): 0.195
Mass Ounce: 0.4099
Thickness (mm): 3.175
Outer diameter(mm): 25.4
Inner Diameter (mm): 4.953
Mass(g): 11.62
Countersink: 0
magnet_family: Spring
peak force: -10.40
Outer diameter fractional (Inch): '1"
Thickness fractional(inch): '1/8"
Magnet Alignment: 0
Self Aligning: NO
Shear resistance: 0
magnet_fun_latch: 0
magnet_fun_spring: Spring
magnet_fun_torque: 0
magnet_fun_symmetry: Radial
Magnet to metal: NO
Shear force: 1_5mm seperation file: 0
magnet_shipping_weight: 0.05
magnet_ring_thickness_mm: 3.175
magnet_ring_od_range: 25.4
magnet_fun_indexing_feature:
0
magnet_ring_length_range:
1
magnet_ring_width_range:
1
magnet_ring_innerdiameter:
4.95
