1001051
Attach Polymagnet - long range - 2D shear resistance
This magnet pairs with itself.
This Polymagnet provides high holding in magnet to magnet-and-magnet to steel applications. It also provides enhanced two-dimensional shear resistance in magnet-to-magnet applications.
More Information
SKU: 1001051
Meta Description: 1001051
Part number: 1001051
Pairs with: 1001051
Availability date: Released
Base Polarity: South
Magnetization orientation: Through Thickness
Coating: Ni-Cu-Ni
Material: NdFeB
Grade: N50
Temperature Rating (C): 60
Temperature Grade: Standard
Shape type: Square
Length (inch): 1
Width (inch): 1
Thickness (inch): 0.062
Mass (oz): 0.2624
Length (mm): 25.4
Width (mm): 25.4
Thickness (mm): 1.587
Mass (g): 7.44
Countersink: 0
Magnet Family: Attach
Length fractional (inch): '1"
Alignment Functionality: 0
Shear resistance: Two Dimensional Shear
Latch Functionality: 0
Spring Functionality: 0
Torque Functionality: 0
Magnet Symmetry: 90
magnet_plate_length_range: 25.4
Indexing Feature: 0
