1001068
Attach Polymagnet - medium range - 2D shear resistance
This magnet pairs with itself and the following: 1001069
This Polymagnet provides high holding force in magnet-to-magnet and magnet-to-steel applications, at design gaps from 0.75 - 1.5mm. It provides enhanced two-dimensional shear resistance in magnet-to-magnet applications.
More Information
SKU 1001068
Meta Description 1001068
Part number 1001068
Pairs with 1001068
Availability date Released
Base Polarity South
Magnetization orientation Through Thickness
Coating Ni-Cu-Ni
Material NdFeB
Grade N50
Temperature Rating (C) 60
Temperature Grade Standard
Shape type Square
Length (inch) 0.5
Width (inch) 0.5
Thickness (inch) 0.125
Mass (oz) 0
Length (mm) 12.7
Width (mm) 12.7
Thickness (mm) 3.175
Mass (g) 0
Countersink 0
Magnet Family Attach
Length fractional (inch) 1/2"
Alignment Functionality 0
Shear resistance Two Dimensional Shear
Latch Functionality 0
Spring Functionality 0
Torque Functionality 0
Magnet Symmetry 90
magnet_plate_length_range 12.7
Indexing Feature 0
Pairs well with
1001068
