1001099

SKU: 1001099
Meta Description: 1001099
Part number : 1001099
Pairs with: 1001099
Availability date: Released
Base Polarity: South
Magnetization orientation: Through Thickness
Coating: Ni-Cu-Ni
Material: NdFeB
Grade: N50
Temperature Rating (C): 60
Temperature Grade: Standard
Dimension tolerance: 0.127
Shape type: Rectangle
Length (inch): 1
Width (inch): 0.25
Thickness (inch): 0.063
Mass (oz): 0.0677
Length (mm): 25.4
Width (mm): 6.35
Thickness (mm): 1.59
Mass (g): 1.92
Countersink:0
Magnet Family: Conventional
Length fractional (inch): 1"
Width fractional (inch): 1/4"
peak force: 20.02
Thickness fractional (inch):1/16"
Shear resistance:0
Latch Functionality:0
Spring Functionality:0
Torque Functionality:0
Magnet Symmetry:0
magnet_plate_od_range: 1
magnet_shipping_weight: 0.05
magnet_disc_length_range: 1
magnet_plate_length_range: 25.4
magnet_plate_width_range:6.35
magnet_plate_thickness_mm: 1.59
magnet_plate_inner diameter: 1
Indexing Feature:0
