1002033
Mobile Device Portrait/Landscape Polymagnet - mount side
This magnet must be paired with the following:
1002032
The Mobile Device Portrait/Landscape Polymagnets are specifically engineered for auto, tabletop or wall mount accessories for mobile phones. They provide a stronger attachment force as well as a unique 90-degree rotational alignment force over conventional magnets. These Polymagnets are designed to provide a high holding force when aligned and very little attractive force when out of alignment, allowing the user to rotate the device easily between locking positions. As these magnets approach alignment, they provide a positive force toward the alignment position. These Polymagnets also exhibit a tightly controlled magnetic field which minimizes interference with sensitive devices.
More Information
SKU 1002033
Meta Description 1002033
Part number 1002033
Pairs with 1002032
Availability date Released
Base Polarity North
Magnetization orientation Through Thickness
Coating Ni-Cu-Ni
Material NdFeB
Grade N50
Temperature Rating (C) 60
Temperature Grade Standard
Shape type D-shape
Length (inch) 1
Thickness (inch) 0.137
Outer diameter (inch) 1
Mass (oz) 0
Length (mm) 25.4
Thickness (mm) 3.48
Outer diameter (mm) 25.4
Mass (g) 0
Countersink 0
Magnet Family Align
Length fractional (inch) 1"
Alignment Functionality Rotational Alignment
Shear resistance Rotational Shear Resistance
Latch Functionality 0
Spring Functionality 0
Torque Functionality 0
Magnet Symmetry 0
magnet_dshape_length_range 1
Indexing Feature D-shape
Pairs well with
1002033
