1000327
Attach Polymagnet - long range - 1D shear resistance
This magnet pairs with itself.
This N40 grade Polymagnet is being retired in favor of higher material grades. After the remaining stock is sold, it will only be available in quantities of 100 or more by special ordering through orders@polymagnet.com.
This Polymagnet provides high holding force in magnet to magnet and magnet to steel applications, at design gaps greater than 1.5 mm. It provides enhanced shear resistance in magnet to magnet applications.
More Information
SKU: 1000327
Meta Description: 1000327
Part number: 1000327
Pairs with: 1000327
Availability date: Released
Base Polarity: South
Magnetization orientation: Through Thickness
Coating: Ni-Cu-Ni
Material: NdFeB
Grade: N40
Temperature Rating (C): 80
Temperature Grade: Standard
Shape type: Rectangle
Length (inch): 2
Width (inch): 0.5
Thickness (inch): 0.062
Mass (oz): 0.2663
Length (mm): 50.8
Width (mm): 12.7
Thickness (mm): 1.587
Mass (g): 7.55
Countersink: 0
Magnet Family: Attach
Length fractional(inch): '2"
Alignment Functionality: 0
Shear resistance: One Dimensional Shear
Latch Functionality: 0
Spring Functionality: 0
Torque Functionality 0
Magnet Symmetry: 0
magnet_plate_length_range: 50.8
Indexing Feature: 0
Pairs well with
1000327
